Smartia M450
Smartia M450
Smartia M450
W are proud to offer the SMARTIA M450, an advanced sliding and lift & slide insulated system that embodies the next generation of minimalistic design and high performance. This system is meticulously crafted to meet the stringent demands of contemporary residences, providing exceptional thermal insulation and a sleek, modern aesthetic.
The SMARTIA M450 is an ideal choice for homeowners and architects seeking a harmonious blend of minimalist design and high-performance functionality. Its advanced features and versatile applications make it a standout solution for modern living spaces.
For more information or to discuss how the SMARTIA M450 can enhance your project, please contact Everhaus Windows.
Advantages
- Minimal and innovative design with only 25 mm of visible aluminium face width at the interlocking profile, both for lift & slide and sliding typologies
- High energy savings thanks to the exceptional energy efficiency
- Great ease of use and high functionality
- Easy to clean frame, with invisible water evacuation and less visible depth
- Wide variety of typologies
- Exceptional quality with certified performance
Specifications
| WINDOW TYPES | THERMAL INSULATION | EXTERIOR SHAPES | UF |
|---|---|---|---|
| Lift & Sliding, Slidin | Yes | Flat | from 1,3 W/m²K |
| MINIMUM THRESHOLD HEIGHT | WATER TIGHTNESS | FRAME DEPTH | SASH WEIGHT |
|---|---|---|---|
| 45 mm | 9A | 113 mm | up to 200 Kg lift & slide, up to 180 Kg sliding |
| SOUND REDUCTION | MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE) | SEALING METHOD | MECHANISM |
|---|---|---|---|
| 40 dB | 25 mm | Perimetrical with tri-fin brushes and/or EPDM gaskets | Lift & slide mechanism Sliding mechanism |
| MAXIMUM GLAZING THICKNESS | WIND LOAD RESISTANCE | TYPE OF THERMAL INSULATION | TYPES OF TYPOLOGY |
|---|---|---|---|
| 36 mm | C3 | Double - Triple | Horizontal sliding sashes, Meeting stile, Combinations with fly-screen, Pocket typologies |
| MINIMUM VISIBLE ALUMINIUM FACE HEIGHT | AIR PERMEABILITY |
|---|---|
| 124,5 mm lift & slide, 114 mm sliding | 4 |
