The SMARTIA S67 is a state-of-the-art Tilt & Turn system from ALUMIL, designed to deliver exceptional thermal insulation and robust construction. This system is engineered to meet the stringent standards of modern architecture, offering a harmonious blend of performance and aesthetics.

Key Features:

  • Enhanced Thermal Insulation: The SMARTIA S67 is built to provide superior thermal efficiency, ensuring optimal energy savings and comfort in both residential and commercial settings.
  • Durable Construction: Crafted with high-quality materials, this system ensures longevity and reliability, maintaining its performance over time.
  • Versatile Design: The Tilt & Turn functionality offers flexibility in ventilation and ease of use, catering to various architectural requirements.

By integrating the SMARTIA S67 into your projects, you can achieve a balance of energy efficiency, security, and modern design, making it an ideal choice for contemporary building needs.

Advantages

  • Very good value for money
  • High energy savings due to the high energy efficiency of the system
  • Increased level of security
  • High level of sound insulation
  • Ease of use and high functionality
  • Modern design for windows either with flat or curved line
  • Ease of access according to specifications for people with special needs and children
  • High quality with certified performances
  • Increased static loads and functionality in case of severe weather conditions
A close up of a sliding glass door on a white background.

Specifications

WINDOW TYPES THERMAL INSULATION EXTERIOR SHAPES UF
Hinged Yes Flat from 1,1 to 2,6 W/m²K
FRAME DEPTH SASH DEPTH MINIMUM VISIBLE ALUMINIUM FACE HEIGHT MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (ADJOINING PROFILE)
67 mm 75 mm 93 mm 67 mm
GLAZING TYPE MAXIMUM GLAZING THICKNESS MECHANISM SEALING METHOD
Double - Triple up to 58 mm Euro-groove, Euro-nut Perimetrical at 3 levels with EPDM gaskets
MINIMUM THRESHOLD HEIGHT TYPE OF THERMAL INSULATION WATER TIGHTNESS AIR PERMEABILITY
13 mm 30mm fiber glass polyamides, PE insulation Foam CLASS Ε1200 CLASS 4
WIND LOAD RESISTANCE SOUND REDUCTION BURGLAR RESISTANCE SASH WEIGHT
Class: C5 45 dB RC2/RC3 up to 180 Kg

Certificates

A red and black logo for a company called atg
A logo for dta document technique d' application supreme s77
A certified cradle to cradle silver logo
The eco platform epd verified logo is green and black.
A blue sign that says aluminum ok recycled and tuv austria architectural aluminum profiles
