Supreme SF85

SUPREME SF85

Supreme SF85

At Everhaus Windows, we are proud to offer the SUPREME SF85 Insulated Folding Door System, a premium solution that seamlessly blends minimalistic design with exceptional performance. This advanced system is engineered to meet the demands of both residential and commercial projects, providing expansive openings without compromising on energy efficiency or security.


The SUPREME SF85 is an ideal choice for those seeking to create large, open spaces that seamlessly integrate indoor and outdoor environments. Its combination of aesthetic appeal, high performance, and security makes it a standout option for modern architectural projects.

For more information or to discuss how the SUPREME SF85 can be integrated into your next project, please contact Everhaus Windows.

A living room with a lot of windows and a view of the ocean.

Advantages

  • Very large dimension in terms of height (up to 4.0m), vent width (up to 1.5m)and total span width
  • Amazingly reduced sight lines which contributes to the overall minimal design
  • Extensive variety of solutions, with odd and even number of vents, corner construction, semi-structural vent version, inwards and outwards opening
  • Extreme performance in terms of air permeability, wind load resistance and water tightness
  • Significant energy and cost saving due to the excellent thermal insulation and U-values (as low as 1.0 W/m2K)
  • Enhanced levels of security and burglar protection, meeting all sector security standards
  • Smooth operation and long-lasting flawless functionality
A close up of a sliding glass door on a black background

Specifications

AESTHETICS THERMAL INSULATION APPLICATIONS PANEL
minimal, relatively low sight line Yes residential with 1.5m panel width, commercial with 4.0m panel height, high-end projects aluminium framed panel, semi-structural panel
SASH WIDTH GLAZING POLYAMIDE EXTRA INSULATING FITTINGS
85 mm 21-58mm Double 40mm Alumil energy bar insulation and PE insulation foam
MAIN GASKET LOCKING VISIBLE ALUMINIUM ΜAXIMUM WEIGHT
Single from co-extruded EPDM and foam Quadruple locking latches 105mm 200Kg/ vent
MAXIMUM HEIGHT MAXIMUM PANEL WIDTH WATER TIGHTNESS AIR PERMEABILITY
4,0 m 1,5 m class 7A , IFT class 4, IFT
WIND LOAD RESISTANCE BURGLAR RESISTANCE ΤHERMAL PERFORMANCE PANEL TYPE
class C3/B3, IFT RC2 IFT & PAS24 (UK) 1.1 W/m²K, IFT bottom slide

Certificates

A red and black logo for a company called atg
A logo for dta document technique d' application supreme s77
A certified cradle to cradle silver logo
The eco platform epd verified logo is green and black.
A blue sign that says aluminum ok recycled and tuv austria architectural aluminum profiles

More Folding Doors
